LED灯条恒流IC
1-300mA可调,线路简单,适合用于LED灯条、模组
封装:SOT-23-3; SOT-89-3, SOT-223
XZ1013 is a 24V linear LED driver with adjustable current as high as 300mA (limited by heat
dissipation of the IC package). The device is designed to provide a constant current source
determined by an external sense resistor Rsense. The current is regulated with less than 2.5% error
when input voltage changes from 1.3V to 24V. XZ1013 is designed with a coefficient, which leads to a perfect constant current under a wide environment temperature
range. The number of external component is very limited, a resistor and a capacitor. And the
XZ1013 uses the power from the negative terminal of the LED string, an extra power trace from the
input power of LED lighting module is not necessary.
XZ1013 is available in space saving SOT23-3 and SOT89-3 package.
